New Victron EasySolar II inverter/charger with 70A Solar MPPT and Control Hub
The display reads battery inverter and solar charge controller parameters. This information can also be accessed with a smartphone or other wifi enabled device. In addition wifi can be used to set up the system and to change settings Grid in-line topology
The EasySolar-II GX will use excess PV power to charge the batteries or to feed power back into the grid and will discharge the battery or use power from the grid to supplement a shortage of PV power. In case of a power outage the EasySolar-II GX will disconnect the grid and continue to supply the loads. Loads that should shut down when AC input power is not available can be connected to a second output (not shown). These loads will be taken into account by the PowerControl and PowerAssist function in order to limit AC input current to a safe value. Grid parallel topology
The EasySolar-II GX will use data from the external AC current sensor (must be ordered separately) or power meter to optimise self-consumption and if required to prevent grid feed. In case of a power outage the EasySolar-II GX will continue to supply the critical loads
Pure Sine Wave Output
5500 Watt Peak Power
2400Watt / 3000 VA Continuous
35 Amp Battery Charger
32 Amp Power Transfer Switch (UPS)
Power Assist
MPPT 250V - 75A
Max panel wattage input 4000W
Max panel voltage per string - 250V i
Dimensions h506 x w275 x d237 mm
26kg weight
5 year warranty
