This Solar PV Cable is designed for connecting solar panels to inverters or charge controllers, handling the high voltages required for solar panels in series. It's also well-suited for small wind turbine installations.
Key Features & Specifications:
- available in 4mm² and 6mm² sizes
- rated at 1800V for both indoor and outdoor installations, including exposure to sunlight
- max current rating of 55A
- TUV approved to PV1-F type
- flexible conductors to BS EN 60228:2005, with tinned copper flexible class 5
- special compound cross-linked HT-PVI (LSHF) insulation and HT-PVG (LSHF) sheath
- flame resistant to EN 60332-1-2, UV resistant to HD 605-A1, and ozone resistant to EN 50396
- RoHS compliant: RoHS passed: 2011/65/EC
- temperature range: -40°C to +90°C (max. overload temperature: 120°C, max. short circuit temperature: 250°C)
- tested for at least 25 years of thermal endurance
- core colour in black
Applications & Benefits:
- ideal for connecting solar panels in series or parallel to inverters or charge controllers
- suitable for small wind turbine applications
- designed for long-term use in demanding outdoor conditions
- meets stringent industry standards for safety and performance
