Victron EnergyÕs Buck Boost DC-DC Converter is for charging a 12V or 24V service battery in vehicles with a smart alternator (regenerative braking Euro 5 and Euro 6 engines)
The converter will charge the auxiliary battery with a pre-set charge voltage eliminating high voltages (e.g. Mercedes: 154V) and low voltages.
Deep discharge of the vehicle's starting battery is avoided by a built-in Ôengine runningÕ detection system. The converter can also be activated by means of a programmable input The converter can be fully programmed by means of a simple and user-friendly PC application. (USB type A male to USB type B male cable needed)
The converter can be programmed to charge a 12 V or a 24 V auxiliary battery from either a 12V or a 24V alternator and starter battery. The output current is determined by the following factors:
The maximum charge current setting.
The maximum input current setting.
The maximum operating temperature limit of the converter.
Input Voltage Range - 7 - 35V.
Output Voltage Range - 2 - 30V
Maximum Charge 12V - 100A : 24V - 50A
Dimensions - 288 x 162 x 95mm
Weight - 4.1Kg
Warranty - 5 Years
